Sawdust hammer mill

A hammer mill is also known as a grinder, or pulverizer, KJ Industry supplies the hammer mills to shred your wood chips, rice husk, straw, hay, stalks into fine particles. They are used as size reduction machines for making wood pellets or briquettes if your raw material is in big size.



KJ-HM hammer mill is designed to process wood chips, turn wood chips into sawdust, for preparation to make wood pellets or briquettes. They have been used in wood pellet lines in Vietnam, China, Latvia, Malaysia, and worldwide.





Specification:

Types	KJHM60*45	KJHM60*60	KJHM66*60	KJHM66*80	KJHM66*100	KJHM68*120
Max input size (mm)	30*30*20	30*30*20	30*30*20	30*30*20	30*30*20	30*30*20
Max MC of input	20%	20%	20%	20%	20%	20%
Rotor Diameter(mm)	600	600	660	660	660	660
Rotor Speed(rpm)	2950	2950	2950	2950	2950	2950
Line speed of hammers(m/s)	94	94	102	102	102	102
Width of the chamber(mm)	450	600	600	800	1000	1200
Qty of Hammers(pc)	32	44	64	84	116	144
Main Motor(kW)	45	55	75	90	110/132	160
Capacity (KGS/H)	1800-2000	2500-3000	3500-4000	4500-5000	5500-6000	6000-8000
Dimension(mm)	1700*500*1200	2100*1070*1230	2150*11300*1260	2250*1300*1260	2650*1320*1280	3100*1380*1330
Weight(kgs)	900	1200	1500	1800	2350	3040



How does the hammer mill perform? Please click the VIDEO.
